Block Cutting Machine
This block cutting machine is for cutting granite and marble blocks in small size. The combination of multiblade with different dimension increases working efficiency. It adopts two slider frame structure, driven synchronizely by double screw, high stiffness and stability.
- SHENGDA
- QUANZHOU
- 25 DAYS
- 60 SETS/MONTH
- Information
- Video
This block cutting machine is for cutting granite and marble blocks in small size. The combination of multiblade with different dimension increases working efficiency. It adopts two slider frame structure, driven synchronizely by double screw, high stiffness and stability.
Technical Parameter:
QSQJ-2000-9 | QSQJ-2500-9 | ||
Blade diameter | mm | 1600～2000 | 1600～2500 |
Max. No. of blades | pc | 9 | 9 |
Max cutting length | mm | 3500 | 3000 |
Max cutting width | mm | 2000 | 2000 |
Max cutting height | mm | 850 | 1100 |
Max vertical stroke of the blade | mm | 200 | 200 |
Variable cutting and return speed | m/min | 0~12 | 0~12 |
Bridge move (Y axis) speed | m/min | 6.5 | 6.5 |
Blade up and down (Z axis) speed | m/min | 3.5 | 3.5 |
Cooling water consumption | m3/h | 15 | 15 |
Blade main motor power | kw(Hp) | 45 (60) | 45 (60) |
Total power | kw(Hp) | 52 (70) | 52 (70) |
Power supply | Vol / Hz | 380 / 50 | 380 / 50 |
Standard installation dimensions (L/W/H) | mm | 7800×4100×6100 | 7800×4100×6300 |
Approximate total weight | kg | 11000 | 11000 |
